Key Features
-
True 12‑lead recording with digital signal processing and filters (baseline, power‑line, EMG), resulting in high‑quality ECG waveforms contechealth.com+6contechealth.com+6sleepsolutions.in+6.
-
Offers auto, manual, and rhythm printing modes, including formats such as 12×1, 6×2+1, 3×4+1, and more, plus rhythm data capture hospitalstore.com+6contechealth.com+6healthoceans.com+6.
-
Auto-analysis engine (via PC software in FDA version) provides measurements and preliminary diagnostics for HR, P‑R, QRS, QT/QTc, axes, amplitudes, etc. contechealth.com+8contechealth.com+8eastshoremedical.com+8.
-
Memory stores up to 1,000 cases, with internal charts and P‑R trend histograms nidhihealthcare.in+7contechealth.com+7healthoceans.com+7.
Printer & Display
-
Thermal printer supporting adjustable paper speeds: 5, 6.25, 10, 12.5, 25, 50 mm/s contechealth.com+11contechealth.com+11vdbiomedisystems.in+11.
-
8″ 800×600 color touchscreen, displayable in 3/6/12‑lead views with sensitivity, filter, and speed overlays ebay.com+9contecmedsystems.com+9eastshoremedical.com+9.
Power & Battery
-
Dual power inputs: AC (100–240 VAC) and DC (14.8 V rechargeable 3,500 mAh battery) kaaryamedical.in+4healthoceans.com+4contecmedsystems.com+4.
-
Up to 10 hours of standby and 3+ hours continuous printing on battery backup amazon.in+5contechealth.com+5contecmedsystems.com+5.
Performance & Safety
-
Sampling rate: 1,000 Hz with 24‑bit resolution kaaryamedical.in+1shop.kaaryamedical.com+1.
-
Input safety: floating circuit with defibrillation protection; patient leakage < 10 µA sleepsolutions.in+7healthoceans.com+7eastshoremedical.com+7.
-
Frequency response: 0.05 Hz–150 Hz; CMRR > 60 dB (>100 dB with filter); EMG filter at 25/35 Hz nidhihealthcare.in+9healthoceans.com+9eastshoremedical.com+9.
-
Sensor sensitivity: 2.5–40 mm/mV; noise ≤ 15 µVpp; input impedance ≥ 50 MΩ contecmedsystems.com+8healthoceans.com+8shop.kaaryamedical.com+8.
-
Certified Class I, Type CF, defibrillation-proof applied part walmart.com+10healthoceans.com+10contechealth.com+10.
Multi-Language Support
Supports interfaces and reports in at least 12 languages, including English, Chinese, French, German, Spanish, Portuguese, Russian, Turkish, and more .
